Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas.
*Please note – spec applies to all sizes unless listed separately
- Frame
-
Alpha Gold Aluminium, internal cable routing, internal battery, rack and mudguard mounts, kickstand mount
- *Fork
-
Size:Â S, M, L, XL
Alloy, internal brake routing, mudguard mounts, rack mounts, ThruSkew 5 mm QR
- Hub front
-
Formula DC-20, alloy, 6-bolt, 100×5 mm
- Skewer front
-
132×5 mm QR
- Hub rear
- Rim
-
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
- Spokes
-
14 g stainless steel, black
- Tyre
-
Bontrager H2 Comp, reflective strip, wire bead, 30 tpi, 700×40 mm
- Battery
- Charger
- Computer
- Max assist speed
- 25Â km/h
- Shifter
-
Shimano M315, 8-speed
- Rear derailleur
-
Shimano Acera M3020-8, 40T max cog
- *Crank
- Bottom bracket
- Cassette
-
Shimano HG400, 11-40, 8-speed
- Chain
-
KMC Z8.3
- Pedal
- Saddle
- *Seatpost
-
Size:Â S, M
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm lengthSize:Â L, XL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length - *Handlebar
-
Size:Â L, XL
Bontrager alloy, 31.8 mm, 15 mm rise, 690 mm width - Grips
- *Stem
-
Size:Â S, M
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm lengthSize:Â L, XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length - Brake
-
Shimano hydraulic disc, MT200 lever, UR300 calliper
- Brake rotor
-
Shimano RT26, 6-bolt, 160 mm
- *Light
-
Size:Â S, M, L, XL
Spanninga SoloSize:Â S, M, L, XL
Herrmans MR4, 120-lumen LED - Kickstand
-
Alloy, rear mount
- *Cargo rack
-
Size:Â S, M, L, XL
MIK-compatible alloy rear rack, maximum load 25 kgSize:Â S, M, L, XL
MIK-compatible alloy rear rack - *Mudguard
-
Size:Â S, M, L, XL
SKS plastic, rearSize:Â S, M, L, XL
SKS plastic, front
- Weight
- M – 17.75 kg / 39.14 lb
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
