*Please note – spec applies to all sizes unless listed separately
- Frame
-
Alpha Platinum Aluminium, tapered head tube, ZS headset, internal derailleur and dropper post routing, ISCG 05, threaded BB, UDH, 148×12Â mm thru axle
- Fork
-
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 150Â mm travel
- Hub front
-
Shimano TC500 alloy, CentreLock, 110×15 mm thru axle
- Hub rear
-
Shimano TC500 alloy, CentreLock, 148×12 mm thru axle
- Skewer rear
- *Rim
-
Size:Â S, M, ML, L, XL
Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valveSize:Â S, M, ML, L, XL
Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve - *Tyre
-
Size:Â S
Bontrager Gunnison Pro XR, Tubeless-Ready, wire bead, 60 tpi, 27.5×2.40″Size:Â M, ML, L, XL
Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29×2.40″ - Rim strip
- Max tyre size
- Frame: 29×2.60″, Fork: See manufacturer
- Shifter
-
Shimano U6000, 10-speed
- Rear derailleur
-
Shimano CUES U6000 GS
- Crank
-
Shimano CUES U6000, 30T, 55Â mm chain line, 170Â mm length
- Bottom bracket
-
Shimano BB-MT501 BSA
- Cassette
-
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
- Chain
-
Shimano LG500
- Pedal
- Max. chainring size
- 1x: 34T, min 28T
- Saddle
-
Bontrager Verse P3, steel rails
- *Seatpost
-
Size:Â S
TranzX JD-YSI34, 150 mm travel, internal routing, 31.6 mm, 456 mm lengthSize:Â M, ML
TranzX JD-YSI34, 170mm travel, internal routing, 31.6 mm, 500mm lengthSize:Â L, XL
TranzX JD-YSI34, 200mm travel, internal routing, 31.6 mm, 565mm length - *Handlebar
-
Size:Â S
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm widthSize:Â M, ML, L, XL
Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width - Grips
- *Stem
-
Size:Â S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm lengthSize:Â M, ML, L, XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length - Head set
- Brake rotor
-
Shimano RT10, CenterLock, 180 mm
- Brake Set
-
Shimano MT200 hydraulic disc
- Rotor size
- Max brake rotor sizes – Frame: 203 mm, min 180 mm, Fork: see fork manufacturer
- Weight
- M – 14.53 kg/32.04 lb (with TLR sealant, no tubes)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
