*Please note – spec applies to all sizes unless listed separately
- *Frame
-
Size:Â XXS , XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkewSize:Â S , M , ML , L , XL , XXL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkew - *Fork
-
Size:Â XXS
SR Suntour XCM 30, coil spring, lockout, preload, 100 mm QR, 100 mm travel, 26″ wheelSize:Â XS
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5″ wheel, 100 mm QR, 80 mm travelSize:Â S
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5″ wheel, 100 mm QR, 100 mm travelSize:Â M , ML , L , XL , XXL
SR Suntour XCE 28, coil spring, preload, 46 mm offset for 29″ wheel, 100 mm QR, 100 mm travel
- Hub front
-
Formula DC-20, alloy, 6-bolt, 100×5 mm
- Skewer front
- Hub rear
-
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135×5 mm
- Skewer rear
- Rim
-
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
- *Tyre
-
Size:Â XXS
Bontrager Montrose Comp, wire bead, 30Â tpi, 26×2.35”Size:Â XS , S
Bontrager Montrose Comp, wire bead, 30 tpi, 27.5×2.40″Size:Â M , ML , L , XL , XXL
Bontrager Montrose Comp, wire bead, 30 tpi, 29×2.40″
- Shifter
-
Shimano M315, 8-speed
- Rear derailleur
-
Shimano ESSA U2000
- *Crank
-
Size:Â XXS , XS
ProWheel alloy, 30T narrow-wide steel ring, 160Â mm lengthSize:Â S , M , ML
ProWheel alloy, 30T narrow-wide steel ring, 170Â mm lengthSize:Â L , XL , XXL
ProWheel alloy, 30T narrow-wide steel ring, 175Â mm length - Bottom bracket
-
Threaded cartridge
- Cassette
-
Shimano HG300, 11-45, 8-speed
- Chain
-
KMC Z8.3, 8-speed
- Pedal
-
Nylon platform
- Saddle
- *Seatpost
-
Size:Â XXS
Bontrager alloy, 31.6Â mm, 12Â mm offset, 300Â mm lengthSize:Â XS , S , M
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm lengthSize:Â ML , L , XL , XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length - *Handlebar
-
Size:Â XXS , XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm widthSize:Â S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm widthSize:Â M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width - Grips
- *Stem
-
Size:Â XXS , XS , S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm lengthSize:Â M , ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm lengthSize:Â XXL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length - Head set
-
Semi-integrated, 1-1/8”
- *Brake
-
Size:Â XXS , XS , S
Tektro HD-M276 hydraulic discSize:Â XXS , XS , S , M , ML , L , XL , XXL
Power BH-M286TF hydraulic disc, 160 mm rotorSize:Â M , ML , L , XL , XXL
Tektro HD-M275 hydraulic discSize:Â M , ML , L , XL , XXL
Power BH-M286TF hydraulic disc, 180 mm rotor - *Brake rotor
-
Size:Â XXS , XS , S , M , ML , L , XL , XXL
Tektro, 6-bolt, 160mmSize:Â M , ML , L , XL , XXL
Tektro, 6-bolt, 180mm
- Weight
- M – 14.90 kg / 32.85 lbs
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
