*Please note – spec applies to all sizes unless listed separately
- Frame
-
500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden mudguard mounts, rack mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142×12 mm chamfered thru axle
- Fork
- Weight
- ML – 9.50 kg/20.95 lb (with TLR sealant, no tubes)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
- Battery
-
SRAM AXS battery pack (with charger)
- Shifter
-
SRAM Apex AXS, 12-speed
- Rear derailleur
-
SRAM Apex XPLR eTap AXS, 44T max cog
- *Crank
-
Size:Â XS, S
SRAM Apex 1, 40T, DUB Wide, 165 mm lengthSize:Â M
SRAM Apex 1, 40T, DUB Wide, 170 mm lengthSize:Â ML, L
SRAM Apex 1, 40T, DUB Wide, 172.5 mm lengthSize:Â XL
SRAM Apex 1, 40T, DUB Wide, 175 mm length - Bottom bracket
-
SRAM DUB Wide, T47 threaded, internal bearing
- Cassette
-
SRAM XPLR PG-1231, 11-44, 12-speed
- Chain
-
SRAM Apex, 12-speed
- Max. chainring size
- 1x:44 2x: 46/30
- Wheel front
-
Bontrager Paradigm SL, Tubeless Ready, 21 mm rim width, 100×12 mm thru axle
- Wheel rear
- Skewer front
- Skewer rear
- Tyre
-
Bontrager Girona RSL, Tubeless Ready, GR puncture protection, aramid bead, 220 tpi, 700×42 mm
- Tyre part
-
Bontrager TLR sealant, 180 ml/6 oz
- Rim strip
- Max tyre size
- 50 mm without mudguards, 42 mm with mudguards (as measured, see manual for details)
- *Saddle
-
Size:Â XS, S
Verse Short Comp, steel rails, 155 mm widthSize:Â M, ML, L, XL
Verse Short Comp, steel rails, 145 mm width - Seatpost
-
Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length
- *Handlebar
-
Size:Â S, M
Bontrager Elite Gravel, alloy, 42 cm widthSize:Â ML, L
Bontrager Elite Gravel, alloy, 44 cm width - Handlebar tape
-
Bontrager Supertack Perf tape
- *Stem
-
Size:Â XS
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm lengthSize:Â S
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm lengthSize:Â M, ML
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm lengthSize:Â L
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm lengthSize:Â XL
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length - Brake rotor
-
SRAM Paceline, rounded, CentreLock, 160 mm
- Rotor size
- Max brake rotor sizes: 180 mm front and rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
