- Frame
-
Size:Â XS , S
Alpha Silver Aluminium, curved top tube, internal routing, chainstay disc brake mount, rack and kickstand mount, 135×5 mm QRSize:Â M , ML , L , XL , XXL
Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135×5 mm QR - *Fork
-
Size:Â XS
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5″ wheel, 100 mm QR, 80 mm travelSize:Â S
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5″ wheel, 100 mm QR, 100 mm travelSize:Â M , ML , L , XL , XXL
SR Suntour XCE 28, coil spring, preload, 46 mm offset for 29″ wheel, 100 mm QR, 100 mm travel
- Hub front
-
Formula DC-20, alloy, 6-bolt, 100×5 mm
- Hub rear
-
Formula DC-31, alloy, 6-bolt, 6/7/8-speed freewheel, 135×5 mm
- Skewer rear
- Rim
-
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
- Spokes
-
14 g stainless steel, black
- *Tyre
-
Size:Â XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5×2.20″Size:Â M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29×2.20″ - Max tyre size
- Frame: 29×2.20″ (XS & S: 27.5×2.40″), Fork: See manufacturer
- *Shifter
-
Size:Â XS , S , M , ML , L , XL , XXL
Shimano EF500, 2-speedSize:Â XS , S , M , ML , L , XL , XXL
Shimano Altus EF500, 7-speed - Front derailleur
-
Shimano Altus M315, 34.9 mm clamp, top swing, dual pull
- Rear derailleur
-
Shimano Tourney TY300
- *Crank
-
Size:Â XS , S , M
ProWheel TM-CY10, 36/22, 170 mm lengthSize:Â ML , L , XL , XXL
ProWheel TM-CY10, 36/22, 175 mm length - Bottom bracket
-
VP BC73, 73 mm, threaded cartridge
- Cassette
-
Shimano TZ500, 14-34, 7-speed
- Chain
-
KMC Z7, 7-speed
- Pedal
- Max. chainring size
- 1x: See FAQ, 2x: 36T, 3x: 42T
- Saddle
- *Seatpost
-
Size:Â XS , S
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm lengthSize:Â M
Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm lengthSize:Â ML , L , XL , XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length - *Handlebar
-
Size:Â XS , S
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm widthSize:Â M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width - Grips
- *Stem
-
Size:Â ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm lengthSize:Â XL , XXL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length - Head set
-
Semi-integrated, 1-1/8″
- *Brake
-
Size:Â XS , S , M , ML , L , XL , XXL
Tektro MD-M280 mechanical discSize:Â XS , S , M , ML , L , XL , XXL
Tektro MD-M281 mechanical discSize:Â XS , S , M , ML , L , XL , XXL
Tektro MD-M280 mechanical disc, 160 mm rotorSize:Â XS , S , M , ML , L , XL , XXL
Tektro MD-M281 mechanical disc, 160 mm rotor - Brake rotor
-
Tektro wave, 6-bolt, 160 mm
- Rotor size
- Max brake rotor sizes – Frame: 180mm, min 160mm, Fork: see fork manufacturer
- Weight
- M – 14.60 kg / 32.19 lb
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
